2-Handle Exposed Shower Less Head LSP

SKU SC-1210-LH-LSP Categories , ,

The SC-1210-AF is an exposed chrome plated brass shower with polished chrome plated brass risers and gooseneck. The SC-1210-AF features 1/4 turn ceramic cartridges and four-arm cross handles with color-coded indexes. The valve body is reversible on 6 In. centers. Included with the SC-1210-AF is an S-2272-E2 showerhead.

  • Cross Handles
  • Showerhead not included
  • Excludes supply pipes
  • Meets ASME A112.18.1/CSA B125.1 standards
Request a Quote or Sample

Additional information

Weight 67578171 kg
Dimensions 67594172 × 6723697 cm
Product finish

Polished Chrome
Length

7.0
Collection

Product style

Commercial
Number of holes

Installation type

Wall Mounted
  • Activation type: Rotate Handle
  • Assembly required: No
  • Connection size: 1/2" NPT male
  • Connection type: Threaded Pipe
  • Country of origin: China
  • Diverter included: No
  • Drain included: No
  • Escutcheon included: No
  • Faucet center measurement: 6
  • Faucet handle style: Cross
  • Faucet operation: Manual
  • For use with: Repair Part RPG04-0323-PC Cross Handle with Indexes & Sleeves
  • Handle location: Side
  • Handles included: Yes
  • Integral stops: No
  • Massage feature: No
  • Material composition: Brass
  • Number of faucet handles: 2
  • Pause control: No
  • Products this item repairs: RPG04-0323-PC
  • Repair part: RPG04-0323-PC
  • Repair part for catalog: RPG04-0323-PC - Speakman Repair Part RPG04-0323-PC Cross Handle with Indexes & Sleeves
  • Rough-in valve template included: Yes
  • Scald guard included: No
  • Self-cleaning nozzles: No
  • Shower arm included: Yes
  • Temperature limit control: No
  • Tools needed for assembly: Phillips screwdriver; adjustable wrench; pipe wrench; strap wrench; teflon tape; drill; drill bits
  • Valve included: Yes
  • Valve type: Ceramic
  • Vandal resistant: No
  • Weight: 4.05
  • Width: 6.0

Instruction manual

Spec Sheet

Sell Sheet

CAD file 1

CAD file 2

CAD file - Revit

CAD file - SketchUp

  • ADA compliant: Yes
  • ASME A112.181/CSA B125.1 IAPMO certified: Yes
  • IGC 272 IAPMO certified: No
  • Low lead law IAPMO certified: No
  • Meets ARRA: No
  • NSF61 IAPMO certified: No
  • State restrictions: CA, HI, OR, WA
  • Consumer warranty: 5 Year Limited
  • Commercial warranty: 5 Year Limited
