Echo Shower Valve

SKU CPV-12000 Categories , ,

The Speakman Echo CPV-12000 Shower Valve has been engineered to deliver a complete and consistent shower experience. Featuring a pressure balancing and temperature regulating ceramic cartridge this shower valve ensures water will be delivered without ever becoming scalding hot. The Echo Shower Valve is exclusively compatible with the Echo CPT-12000 Shower Valve Trim.

  • Features a pressure balancing and temperature regulating ceramic disc cartridge
  • Includes an adjustable temperature limit stop
  • Equipped with integral stops
  • Exclusively compatible with the Echo CPT-12000 Valve Trim
  • ASME A112.18.1/CSA B125.1 & ASSE 1016 certified
Request a Quote or Sample

Additional information

Weight 67578171 kg
Dimensions 67594172 × 6723697 cm
Product finish

Black
Length

4.875
Collection

Product style

Modern
Number of holes

Installation type

Wall Mounted
  • Activation type: Rotate Handle
  • Assembly required: Yes
  • Connection size: 0.5
  • Connection type: NPT and Sweat/Solder
  • Country of origin: China
  • Diverter included: No
  • Drain included: No
  • Escutcheon included: No
  • For use with: Echo RPG05-34932 Replacement Shower Valve Bonnet Cap
  • Handles included: No
  • Integral stops: No
  • Massage feature: No
  • Material composition: Brass
  • Pause control: No
  • Products this item repairs: RPG05-34932
  • Repair part: RPG05-34932
  • Repair part for catalog: RPG05-34932 - Speakman Echo RPG05-34932 Replacement Shower Valve Bonnet Cap
  • Rough-in valve template included: Yes
  • Scald guard included: Yes
  • Self-cleaning nozzles: No
  • Shower arm included: No
  • Temperature limit control: Yes
  • Tools needed for assembly: Adjustable Wrench, Pipe Wrench, Phillips Screwdriver, Thread Seal Tape
  • Valve included: Yes
  • Valve type: Ceramic
  • Vandal resistant: No
  • Weight: 1.76
  • Width: 3.3

Instruction manual

Spec Sheet

Sell Sheet

CAD file 1

CAD file 2

CAD file - Revit

CAD file - SketchUp

  • ADA compliant: No
  • ASME A112.181/CSA B125.1 IAPMO certified: Yes
  • Cadmium content: No
  • Chromium content: Yes
  • Lead content: Yes
  • Low lead law IAPMO certified: No
  • Meets ARRA: No
  • Mercury content: No
  • NSF61 IAPMO certified: No
  • Consumer warranty: 5 Year Limited
  • Commercial warranty: 5 Year Limited
