Neo Shower Arm and Flange

SKU S-2540-1 Categories Shower Accessories, Shower Arm and Flange, Showering

Product finish: No selection

Length: No selection

6.94

Clear

Features and Specifications

Additional information

Weight	67578171 kg
Dimensions	67594172 × 6723697 cm
Product finish	Polished Chrome, Brushed Bronze, Brushed Nickel, Matte Black, Oil Rubbed Bronze, Polished Nickel
Length	6.94
Collection	Neo
Product style	Modern
Number of holes	1
Installation type	Wall Mounted

Assembly required: No
Connection size: 1/2 In. NPTM
Connection type: Threaded Pipe
Country of origin: China
Diverter included: No
Drain included: No
Escutcheon included: No
For use with: Neo SM-1010-P Shower System Combination
Handles included: No
Integral stops: No
Massage feature: No
Material composition: Brass & Metal
Pause control: No
Products this item repairs: SM-1010-P
Rough-in valve template included: No
Scald guard included: No
Self-cleaning nozzles: No
Shower arm included: Yes
Temperature limit control: No
Tools needed for assembly: Adjustable wrench; Teflon tape
Type of shower arm: Fixed
Valve included: No
Vandal resistant: No
Weight: 0.7
Width: 1.5

Documentation

Instruction manual

Sell Sheet

CAD file - Revit

CAD file - SketchUp

Environmental and compliance

ADA compliant: No
ASME A112.181/CSA B125.1 IAPMO certified: No
Cadmium content: No
Chromium content: Yes
IGC 272 IAPMO certified: No
Lead content: Yes
Low lead law IAPMO certified: No
Meets ARRA: No
Mercury content: No
NSF61 IAPMO certified: No

Warranty information
