SE-921 Deck Mounted Drench Hose

SKU SE-921 Categories , ,

Ideal for laboratories and industrial settings, the Speakman SE-921 Deck Mounted Drench Hose is engineered to provide remarkable flexibility when crisis occurs. Featuring a countertop mounted design, this drench hose can be installed in intuitive locations that are easily accessible. An ultra-versatile, 6-foot hose is housed below the counter, and allows spot on washing to any contaminated area. The SE-921 includes a self-closing valve, an aerated spray outlet, and is ANSI/ISEA Z358.1 certified.

  • Deck mounted installation
  • Singular, aerated spray head
  • Stay-open squeeze valve activation
  • 1.6 gpm at 30 psi
Request a Quote or Sample

Additional information

Dimensions 67594172 × 6723697 cm
Product finish

Polished Chrome
Flow rate

1.5 GPM
Length

5.5
Collection

Product style

Industrial
Installation type

In-Line Mounted
  • Activation type: Squeeze
  • Assembly required: No
  • Connection size: 3/8" NPT Male
  • Connection type: Threaded Pipe
  • Country of origin: Taiwan
  • Diverter included: No
  • Drain included: No
  • Escutcheon included: No
  • Faucet handle style: Squeeze
  • Flow type: Aerated & Laminar
  • For use with: Repair Part RPG05-1177 Aerator Replacement Group - 6 Pack
  • Handle location: Side
  • Handles included: Yes
  • Hose length in inches: 72.0
  • Integral stops: No
  • Massage feature: No
  • Material composition: Brass & Plastic
  • Number of faucet handles: 1
  • Pause control: No
  • Products this item repairs: RPG05-1177
  • Repair part: RPG05-1177
  • Repair part for catalog: RPG05-1177 - Speakman Repair Part RPG05-1177 Aerator Replacement Group - 6 Pack
  • Replacement item for: 75276
  • Rough-in valve template included: No
  • Scald guard included: No
  • Self-cleaning nozzles: No
  • Shower arm included: No
  • Special features: Hose Included
  • Temperature limit control: No
  • Tools needed for assembly: Pencil, Drill, Hole Saw, Pipe Wrench, Pipe Thread Sealant
  • Valve included: Yes
  • Valve type: Self-Closing
  • Vandal resistant: No
  • Weight: 3.5
  • Width: 5.5

Instruction manual

Spec Sheet

Sell Sheet

CAD file 1

CAD file 2

CAD file - Revit

CAD file - SketchUp

  • ADA compliant: No
  • ANSI Z358.1 IAPMO certified:Yes
  • ASME A112.181/CSA B125.1 IAPMO certified: No
  • Cadmium content: Yes
  • Chromium content: Yes
  • IGC 272 IAPMO certified: No
  • Lead content: Yes
  • Low lead law IAPMO certified: No
  • Meets ARRA: No
  • Mercury content: No
  • NSF61 IAPMO certified: No
  • Consumer warranty: 3 Year Limited
  • Commercial warranty: 3 Year Limited
