Sentinel Mark II Exposed Shower with S-2272-E2

SKU S-1496-AF Categories Exposed Shower, Showering, Specialty Shower Fixtures

Sentinel Mark II® Exposed Anti-scald Pressure Balanced showers feature a brass lever handle for easy activation. The S-1496-AF has a cast brass rough chrome plated body with adjustable supply stops which allow connection from floor, ceiling or wall. Included with the shower is an S-2272-E2 showerhead and a galvanized gooseneck with supporting strap. The S-1496-AF meets ASME A112.18.1/CSA B125.1 & ASSE 1016 standards.

Rough chrome plated cast brass body
Brass lever handle
Includes S-2272-E2 showerhead
Anti-scald balanced pressure shower valve
An adjustable temperature limit stop prevents scalding
Meets ASME A112.18.1/CSA B125.1 & ASSE 1016 standards

Features and Specifications

Additional information

Weight	67578171 kg
Dimensions	67594172 × 6723697 cm
Product finish	Polished Chrome
Flow rate	1.75 GPM Min. Rated Flow for Shower Valve / 2.0 GPM Max. Flow for Shower Head
Length	8.36
Collection	Sentinel Mark II
Product style	Commercial
Number of holes	2
Spray type	1
Installation type	Wall or Pipe Mounted
Shower function	Single Function

Activation type: Rotate Handle
Assembly required: Yes
Connection size: 1/2 NPT FEMALE
Connection type: NPT
Country of origin: China
Diverter included: No
Drain included: No
Escutcheon included: No
Faucet handle style: Lever
Faucet operation: Manual
Flow type: Spray
For use with: Repair Part RPG03-0371-RCP Valve handle stem washer O-Ring
Handle location: Center of Valve
Handles included: Yes
Integral stops: No
Massage feature: No
Material composition: Brass, Zinc, Stainless Steel, Plastic
Number of faucet handles: 1
Number of jets: 50
Number of shower heads: 1
Pause control: No
Products this item repairs: RPG03-0371-RCP
Repair part: RPG04-0367-PC; RPG05-106096
Repair part for catalog: RPG04-0367-PC; RPG05-106096
Rough-in valve template included: No
Scald guard included: Yes
Self-cleaning nozzles: Yes
Shower arm included: Yes
Shower head face diameter: 2.76
Shower head shape: Round
Temperature limit control: Yes
Tools needed for assembly: Adjustable Wrench; Phillips Screwdriver; Flat Tip Screwdriver; 3/32" Allen Wrench
Type of shower arm: J-Shaped
Valve included: Yes
Valve type: Pressure Balance
Vandal resistant: No
Weight: 3.92
Width: 3.63
