SE-TW-EW Thermostatic Mixing Valve

SKU SE-TW-EW Categories , ,

The Speakman SE-TW-EW Thermostatic Mixing Valve is a thermostatic mixing valve kit for eyewashes. The SE-TW-EW features an STW-370 single element, thermostatic mixing valve capable of supplying 7 GPM of tepid water. The STW-370 provides 5 GPM cold water bypass in case of hot water or thermostatic element failure.

  • Designed for use with single eye or eye/face wash stations
  • Features a 9.7 GPM flow capacity
  • Durable, low lead brass construction
  • Equipped with an adjustable set point
  • Certified to ASSE 1071, CSA B125.3 & NSF/ANSI 372 Standards
  • 3 Year Limited Warranty
Request a Quote or Sample

Additional information

Weight 67578171 kg
Dimensions 67594172 × 6723697 cm
Product finish

Rough Brass
Length

4.5
Collection

Product style

Industrial
Installation type

Wall Mounted
  • Assembly required: No
  • Connection size: 1/2" NPT Female
  • Connection type: Threaded Pipe
  • Country of origin: United States
  • Diverter included: No
  • Drain included: No
  • Escutcheon included: No
  • For use with: Repair Part RPG05-1116 Dial Thermometer Repair Part
  • Handles included: No
  • Integral stops: No
  • Massage feature: No
  • Material composition: Brass
  • Pause control: No
  • Products this item repairs: RPG05-1116
  • Repair part: RPG05-1116
  • Repair part for catalog: RPG05-1116 - Speakman Repair Part RPG05-1116 Dial Thermometer Repair Part
  • Rough-in valve template included: No
  • Scald guard included: No
  • Self-cleaning nozzles: No
  • Shower arm included: No
  • Special features: Includes necessary connections to install with Eeye or eye/face wash
  • Temperature limit control: No
  • Tools needed for assembly: Adjustable wrench; Teflon tape
  • Valve included: Yes
  • Valve type: Thermostatic
  • Vandal resistant: No
  • Weight: 5.18
  • Width: 5.375

Instruction manual

Spec Sheet

Sell Sheet

CAD file 1

CAD file 2

CAD file - Revit

CAD file - SketchUp

  • ADA compliant: No
  • ASME A112.181/CSA B125.1 IAPMO certified: No
  • IGC 272 IAPMO certified: No
  • Low lead law IAPMO certified: No
  • Meets ARRA: Yes
  • NSF61 IAPMO certified: No
  • Consumer warranty: 3 Year Limited
  • Commercial warranty: 3 Year Limited
